Build your Java image
Estimated reading time: 10 minutes
- Build images
- Run your image as a container
- Use containers for development
- Run tests
- Configure CI/CD
- Deploy your app
Work through the orientation and setup in Get started Part 1 to understand Docker concepts. Refer to the following section for Java prerequisites.
Now that we have a good overview of containers and the Docker platform, let’s take a look at building our first image. An image includes everything needed to run an application - the code or binary, runtime, dependencies, and any other file system objects required.
To complete this tutorial, you need the following:
- Java OpenJDK version 15 or later. Download and install Java
- Docker running locally. Follow the instructions to download and install Docker
- A Git client
- An IDE or a text editor to edit files. We recommend using IntelliJ Community Edition.
Let’s clone the sample application that we’ll be using in this module to our local development machine. Run the following commands in a terminal to clone the repo.
$ cd /path/to/working/directory $ git clone https://github.com/spring-projects/spring-petclinic.git $ cd spring-petclinic
Test the application
Let’s start our application and make sure it is running properly. Maven will manage all the project processes (compiling, tests, packaging, etc). The Spring Pets Clinic project we cloned earlier contains an embedded version of Maven. Therefore, we don’t need to install Maven separately on your local machine.
Open your terminal and navigate to the working directory we created and run the following command:
$ ./mvnw spring-boot:run
This downloads the dependencies, builds the project, and starts it.
To test that the application is working properly, open a new browser and navigate to
Switch back to the terminal where our server is running and you should see the following requests in the server logs. The data will be different on your machine.
o.s.s.petclinic.PetClinicApplication : Started PetClinicApplication in 11.743 seconds (JVM running for 12.364)
Create a Dockerfile for Java
Now that our application is running properly, let’s take a look at creating a Dockerfile.
A Dockerfile is a text document that contains all the commands a user could call on the command line to assemble an image. When we tell Docker to build our image by executing the
docker build command, Docker reads these instructions and execute them sequentially and creates a Docker image.
Let’s walk through the steps on creating a Dockerfile for our application. In the root of your working directory, create a file named
Dockerfile and open this file in your text editor.
The name of the Dockerfile is not important but the default filename for many commands is simply
Dockerfile. Therefore, we’ll use that as our filename throughout this series.
The first line to add to the Dockerfile is a
# syntax parser directive.
While optional, this directive instructs the Docker builder what syntax to use
when parsing the Dockerfile, and allows older Docker versions with BuildKit enabled
to upgrade the parser before starting the build. Parser directives
must appear before any other comment, whitespace, or Dockerfile instruction in
your Dockerfile, and should be the first line in Dockerfiles.
We recommend using
docker/dockerfile:1, which always points to the latest release
of the version 1 syntax. BuildKit automatically checks for updates of the syntax
before building, making sure you are using the most current version.
Next, we need to add a line in our Dockerfile that tells Docker what base image we would like to use for our application.
# syntax=docker/dockerfile:1 FROM openjdk:16-alpine3.13
Docker images can be inherited from other images. Therefore, instead of creating our own base image, we’ll use the official Maven image with Java JDK that already has all the tools and packages that we need to run a Java application.
To learn more about creating your own base images, see Creating base images.
To make things easier when running the rest of our commands, let’s create a working directory. This instructs Docker to use this path as the default location for all subsequent commands. By doing this, we do not have to type out full file paths but can use relative paths based on the working directory.
Usually, the very first thing you do once you’ve downloaded a project written in Java which is using Maven for project management is to install dependencies.
Before we can run
mvnw dependency, we need to get the Maven wrapper and our
pom.xml file into our image. We’ll use the
COPY command to do this. The
COPY command takes two parameters. The first parameter tells Docker what file(s) you would like to copy into the image. The second parameter tells Docker where you want that file(s) to be copied to. We’ll copy all those files and directories into our working directory -
COPY .mvn/ .mvn COPY mvnw pom.xml ./
Once we have our
pom.xml file inside the image, we can use the
RUN command to execute the command
mvnw dependency:go-offline. This works exactly the same way as if we were running
mvnw (or mvn) dependency locally on our machine, but this time the dependencies will be installed into the image.
RUN ./mvnw dependency:go-offline
At this point, we have an Alpine version 3.13 image that is based on OpenJDK version 16, and we have also installed our dependencies. The next thing we need to do is to add our source code into the image. We’ll use the
COPY command just like we did with our
pom.xml file above.
COPY src ./src
COPY command takes all the files located in the current directory and copies them into the image. Now, all we have to do is to tell Docker what command we want to run when our image is executed inside a container. We do this using the
CMD ["./mvnw", "spring-boot:run"]
Here’s the complete Dockerfile.
# syntax=docker/dockerfile:1 FROM openjdk:16-alpine3.13 WORKDIR /app COPY .mvn/ .mvn COPY mvnw pom.xml ./ RUN ./mvnw dependency:go-offline COPY src ./src CMD ["./mvnw", "spring-boot:run"]
To use a file in the build context, the Dockerfile refers to the file specified in an instruction, for example, a
COPY instruction. To increase the performance of the build, and to exclude files and directories, we recommend that you create a
.dockerignore file to the context directory. To improve the context load time, add a
target directory within the
Build an image
Now that we’ve created our Dockerfile, let’s build our image. To do this, we use the
docker build command. The
docker build command builds Docker images from a Dockerfile and a “context”. A build’s context is the set of files located in the specified PATH or URL. The Docker build process can access any of the files located in this context.
The build command optionally takes a
--tag flag. The tag is used to set the name of the image and an optional tag in the format
name:tag. We’ll leave off the optional
tag for now to help simplify things. If we do not pass a tag, Docker uses “latest” as its default tag. You can see this in the last line of the build output.
Let’s build our first Docker image.
$ docker build --tag java-docker .
Sending build context to Docker daemon 5.632kB Step 1/7 : FROM java:3.7-alpine Step 2/7 : WORKDIR /app ... Successfully built a0bb458aabd0 Successfully tagged java-docker:latest
View local images
To see a list of images we have on our local machine, we have two options. One is to use the CLI and the other is to use Docker Desktop. As we are currently working in the terminal let’s take a look at listing images using the CLI.
To list images, simply run the
docker images command.
$ docker images REPOSITORY TAG IMAGE ID CREATED SIZE java-docker latest b1b5f29f74f0 47 minutes ago 567MB
You should see at least the we just built
An image name is made up of slash-separated name components. Name components may contain lowercase letters, digits, and separators. A separator is defined as a period, one or two underscores, or one or more dashes. A name component may not start or end with a separator.
An image is made up of a manifest and a list of layers. Do not worry too much about manifests and layers at this point other than a “tag” points to a combination of these artifacts. You can have multiple tags for an image. Let’s create a second tag for the image we built and take a look at its layers.
To create a new tag for the image we’ve built above, run the following command:
$ docker tag java-docker:latest java-docker:v1.0.0
docker tag command creates a new tag for an image. It does not create a new image. The tag points to the same image and is just another way to reference the image.
Now, run the
docker images command to see a list of our local images.
$ docker images REPOSITORY TAG IMAGE ID CREATED SIZE java-docker latest b1b5f29f74f0 59 minutes ago 567MB java-docker v1.0.0 b1b5f29f74f0 59 minutes ago 567MB
You can see that we have two images that start with
java-docker. We know they are the same image because if you take a look at the
IMAGE ID column, you can see that the values are the same for the two images.
Let’s remove the tag that we just created. To do this, we’ll use the
rmi command. The
rmi command stands for “remove image”.
$ docker rmi java-docker:v1.0.0 Untagged: java-docker:v1.0.0
Note that the response from Docker tells us that the image has not been removed but only “untagged”. You can check this by running the
docker images command.
$ docker images REPOSITORY TAG IMAGE ID CREATED SIZE java-docker latest b1b5f29f74f0 59 minutes ago 567MB
Our image that was tagged with
:v1.0.0 has been removed, but we still have the
java-docker:latest tag available on our machine.
In this module, we took a look at setting up our example Java application that we’ll use for the rest of the tutorial. We also created a Dockerfile that we used to build our Docker image. Then, we took a look at tagging our images and removing images. In the next module, we’ll take a look at how to:
